Position switch

Position switch with separate actuator

SIEMENS

...

Binary sensor technology, safety-related sensor technology

Position switch

Position switch with separate actuator

3SE51140QV101AE1

Expand Table

1/5

Product number of the Manufacturer

MANUID

Alternative product number

SUPPLIERALTNO



Short Description

DESCSHORT

Long Description

DESCLONG

EAN

Manufacturer Name

MANUNAME

Manufacturer Type Description

MANUTYPEDESC

Interface design

AAB400

Design of the switching element

AAB412

3SE52423QV40

3SE5242-3QV40

Safety position switch with separate actuator, plastic enclosure, 50 mm

Safety position switch with separate actuator Plastic enclosure, 50 mm Device connection 2x (M20x 1.5) Slow-action contacts 1 NO+2 NC with 2 LEDs yellow/green 115-230 V AC 5 directions of approaches The matching separate actuator 3SE5000-0AV0. must be ordered separately

4011209699861

Siemens

Safety position switch with separate actuator Plastic enclosure, 50 mm Dev

Without

Creep circuit element

3SF11141QV101BA1

3SF1114-1QV10-1BA1

Safety position switch with separate actuator 5 directions of approaches Metal e

Safety position switch with separate actuator 5 directions of approaches Metal enclosure, according to EN 50041 ASIsafe integrated AS-i status: 1:F-IN1, 2: F-IN2 3:AS-i/FAULT Slow-action contacts 2 NC with M12 connector 4-pole Channel 1 to NC, Channel 2 to NC

4011209699878

Siemens

Safety position switch with separate actuator 5 directions of approaches M

Without

Creep circuit element

3SE52420QV40

3SE5242-0QV40

Safety position switch with separate actuator, plastic enclosure, 50 mm

Safety position switch with separate actuator Plastic enclosure, 50 mm Device connection 2x (M20x 1.5) Slow-action contacts 1 NO+2 NC 5 directions of approaches The matching separate actuator 3SE5000-0AV0. must be ordered separately

4011209699670

Siemens

Safety position switch with separate actuator Plastic enclosure, 50 mm Dev

Without

Creep circuit element

3SF11241QV101BA2

3SF1124-1QV10-1BA2

Safety position switch with separate actuator 5 directions of approaches Metal e

Safety position switch with separate actuator 5 directions of approaches Metal enclosure, 56 mm wide ASIsafe integrated AS-i status: 1:F-IN1, 2: F-IN2 3:AS-i/FAULT Slow-action contacts 1 NC with M12 connector 4-pole Channel 1 to NC, Channel 2 to M12 socket on the right

4011209699885

Siemens

Safety position switch with separate actuator 5 directions of approaches M

Without

Creep circuit element

3SF12441QV401BA2

3SF1244-1QV40-1BA2

Safety position switch with separate actuator 5 directions of approaches Plastic

Safety position switch with separate actuator 5 directions of approaches Plastic enclosure 50 mm wide ASIsafe integrated AS-i status: 1:F-IN1, 2: F-IN2 3:AS-i/FAULT Slow-action contacts 1 NC with M12 connector 4-pole Channel 1 to NC, Channel 2 to NC

4011209699908

Siemens

Safety position switch with separate actuator 5 directions of approaches P

Without

Creep circuit element

3SE52320QV40

3SE5232-0QV40

Safety position switch with separate actuator, plastic enclosure, 31 mm

Safety position switch with separate actuator Plastic enclosure, 31 mm Device connection 1x (M20x 1.5) Slow-action contacts 2 NC/1 NO, 5 directions of approach, The matching separate actuator 3SE5000-0AV0. must be ordered separately

4011209699816

Siemens

Safety position switch with separate actuator Plastic enclosure, 31 mm Dev

Without

Creep circuit element

3SE51120QV10

3SE5112-0QV10

Safety position switch with separate actuator, 40 mm, 1X

Safety position switch with separate actuator Metal enclosure, 40 mm Device connection 1x (M20 x 1.5) Slow-action contacts 1 NO/2 NC 5 directions of approaches The matching separate actuator 3SE5000-0AV0. must be ordered separately

4011209699663

Siemens

Safety position switch with separate actuator Metal enclosure, 40 mm Devic

Without

Creep circuit element

3SF12341QV401BA1

3SF1234-1QV40-1BA1

Safety position switch, separate actuator, plastic encl., EN50047, ASIsafe

Safety position switch with separate actuator 5 directions of approaches Plastic enclosure, EN 50047 ASIsafe integrated AS-i status: 1:F-IN1, 2: F-IN2 3:AS-i/FAULT Slow-action contacts 2 NC with M12 connector 4-pole Channel 1 to NC, Channel 2 to NC

4011209699892

Siemens

Safety position switch with separate actuator 5 directions of approaches P

Without

Creep circuit element

3SE52321QV40

3SE5232-1QV40

Safety position switch plastic enclosure, 31 mm 1X

safety position switch with separate actuator plastic enclosure, 31 mm device connection 1x (M20x 1.5) slow-action contacts 1 NO/2 NC with 2 LEDs yellow/green 24 V DC 5 directions of approaches the matching separate actuator 3SE5000-0AV0. must be ordered separately

4011209699823

Siemens

safety position switch with separate actuator plastic enclosure, 31 mm dev

Without

Creep circuit element

3SE51220QV10

3SE5122-0QV10

Safety position switch with separate actuator, 56 mm, 3X

Safety position switch with separate actuator Metal enclosure, 56 mm Device connection 3x (M20x 1.5) Slow-action contacts 1 NO/2 NC 5 directions of approaches The matching separate actuator 3SE5000-0AV0. must be ordered separately

4011209699779

Siemens

Safety position switch with separate actuator Metal enclosure, 56 mm Devic

Without

Creep circuit element

3SE51140QV101AE1

3SE5114-0QV10-1AE1

Safety position switch with separate actuator, 40 mm, 1X

Safety position switch with separate actuator Metal enclosure, 40 mm Slow-action contacts 2 NC with M12 connector, plastic 5-pole, Max. 125 V, 4 A, 2 NC connected, 5 directions of approach. The matching separate actuator 3SE5000-0AV./W. must be ordered separately.

4011209699762

Siemens

Safety position switch with separate actuator Metal enclosure, 40 mm Slow-

Without

Creep circuit element

3SE52320RV40

3SE5232-0RV40

Safety position switch with separate actuator, plastic enclosure, 31 mm

Safety position switch With separate actuator Plastic enclosure, 31 mm Device connection 1x (M20x 1.5) Slow-action contacts 1 NC/1 NO 5 directions of approach The matching separate actuator 3SE5000-0AV0./-0AW. must be ordered separately

4011209712720

Siemens

Safety position switch With separate actuator Plastic enclosure, 31 mm Dev

Without

Creep circuit element

3SE52420RV401AA1

3SE5242-0RV40-1AA1

Safety position switch with separate actuator, plastic enclosure

Safety position switch with separate actuator Plastic enclosure, 50 mm Device connection 2x (M20x 1.5) Slow-action contacts 1 NO+1 NC 5 directions of approaches Pull-out force 30 N The matching separate actuator 3SE5000-0AV0. must be ordered separately

4011209859562

Siemens

Safety position switch with separate actuator Plastic enclosure, 50 mm Dev

Without

Creep circuit element

3SE51320QV20

3SE5132-0QV20

Safety position switch with separate actuator, 1 NO + 2 NC

Safety position switch with separate actuator Plastic enclosure 40 mm 1 x (M20 x 1.5) Slow-action contacts 1 NO+2 NC 5 directions of approaches The matching separate actuator 3SE5000-0AV0. must be ordered separately

4011209878044

Siemens

Safety position switch with separate actuator Plastic enclosure 40 mm 1 x

Without

Creep circuit element

3SE51220QV101AA7

3SE5122-0QV10-1AA7

Safety position switch with separate actuator, metal, pull-out force 30N

Safety position switch with separate actuator Metal enclosure, 56 mm Device connection 3x (M20x 1.5) Slow-action contacts 1 NO/2 NC 5 directions of approaches Pull-out force 30 N separate actuators actuator 3SE5000-0AV0. must ordered separately

4011209859548

Siemens

Safety position switch with separate actuator Metal enclosure, 56 mm Devic

Without

Creep circuit element

3SE51120QV101AA7

3SE5112-0QV10-1AA7

Safety position switch, 1 NO/2 NC, 5 directions of approach

Safety position switch with separate actuator, Metal enclosure 40 mm, Device connection 1x (M20 x 1.5) Slow-action contacts 1 NO/2 NC, 5 directions of approaches, increased pull-out force 30 N, separate actuator 3SE5000-0AV0. must be ordered separately

4011209859531

Siemens

Safety position switch with separate actuator, Metal enclosure 40 mm, Devi

Without

Creep circuit element

3SE52320QV401AA1

3SE5232-0QV40-1AA1

Safety position switch with separate actuator, 1 NO + 2 NC

Safety position switch with separate actuator Plastic enclosure, 31 mm Device connection 1x (M20x 1.5) Slow-action contacts 2 NC/1 NO, 5 directions of approach Pull-out force 30 N, The matching separate actuator 3SE5000-0AV0. must be ordered separately

4011209859555

Siemens

Safety position switch with separate actuator Plastic enclosure, 31 mm Dev

Without

Creep circuit element

3SF12141QV401BA1

3SF1214-1QV40-1BA1

Safety position switch with separate actuator 5 directions of approaches Metal e

Safety position switch with separate actuator 5 directions of approaches Metal enclosure, according to EN 50047 31 mm, ASIsafe integrated AS-i status: 1:F-IN1, 2: F-IN2 3:AS-i/FAULT Slow-action contacts 2 NC with M12 connector 4-pole Channel 1 to NC, Channel 2 to NC

4011209862340

Siemens

Safety position switch with separate actuator 5 directions of approaches M

Without

Creep circuit element

3SE52120QV40

3SE5212-0QV40

Safety position switch with separate actuator, metal enclosure, 31 mm

Safety position switch with separate actuator Metal enclosure 31 mm, 1x (M20x 1.5) Slow-action contacts 1 NO+2 NC 5 directions of approaches The matching separate Actuator 3SE5000-0AV0./-0AW. must be ordered separately

4011209862593

Siemens

Safety position switch with separate actuator Metal enclosure 31 mm, 1x (M

Without

Creep circuit element

Show compressed display (46 products)
