FSGA 53 NBR-55 G1/4-IG
1/5
Type
CNSORDERNO
Part no.
ARTNR
Customs Tariff Number
CTN
d2
D2 [mm]
Dmax(S)
DMAX [mm]
dn
DN [mm]
Ds
DS [mm]
G1
G1
H
H [mm]
LG1
LG1 [mm]
SW1
SW1 [mm]
Stroke
Z [mm]
Suction cup material
SCM
Material hardness
MH
Size
S
Number of folds
NOF
Connection
C
Curve radius (min) (convex)
CR [mm]
Volume
V [cm^3]
1
FSGA 53 NBR-55 G1/4-IG
10.01.06.00066
40169997
33
60
4.4
53
G1/4"-F
49
12
17
12
Nitrile rubber NBR
55 Shore A
53
1.5
G1/4"-F
100
26.49
Schmalz - Bellows Suction Cups FSGA (1.5 Folds)
| Order number | 10.01.06.00066 |
| Shorttext | FSGA 53 NBR-55 G1/4-IG |
| Sista förändringen | 26.08.2024 12:32:35 |
| Enhet |
