VKB-40-160K-M-CR3
1/5
Type
TYPE
Maximum recommended working pressure
MB [kg/cm^2]
Nominal flange size
NDM
Material
MAT
Bolts
BOLT
Bolts
BOLT1
Special request
SPRE
Special request info
SPREINFO
LOD level
LODLEVEL
A1 [mm]
A2 [mm]
LK [mm]
1
2
3
4
5
6
7
8
9
10
11
12
Flange plug with o-ring groove (flange plug including square or round flange respectively, o-ring and bolts)
160
12
Steel
Metric bolts
4 x M10x35
No
High
28.0
17.5
44
Flange plug with o-ring groove (flange plug including square or round flange respectively, o-ring and bolts)
160
16
Steel
Metric bolts
4 x M10x35
No
High
38.0
27.0
54
Flange plug with o-ring groove (flange plug including square or round flange respectively, o-ring and bolts)
160
20
Steel
Metric bolts
4 x M10x35
No
High
38.0
27.0
54
Flange plug with o-ring groove (flange plug including square or round flange respectively, o-ring and bolts)
160
25
Steel
Metric bolts
4 x M12x35
No
High
46.0
34.0
64
Flange plug with o-ring groove (flange plug including square or round flange respectively, o-ring and bolts)
160
32
Steel
Metric bolts
4 x M12x40
No
High
54.5
43.0
72
Flange plug with o-ring groove (flange plug including square or round flange respectively, o-ring and bolts)
160
40
Steel
Metric bolts
4 x M16x50
No
High
60.0
48.3
80
Flange plug with o-ring groove (flange plug including square or round flange respectively, o-ring and bolts)
160
50
Steel
Metric bolts
4 x M16x60
No
High
76.0
60.3
98
Flange plug with o-ring groove (flange plug including square or round flange respectively, o-ring and bolts)
160
65
Steel
Metric bolts
4 x M20x70
No
High
92.0
77.0
118
Flange plug with o-ring groove (flange plug including square or round flange respectively, o-ring and bolts)
160
80
Steel
Metric bolts
4 x M30x90
No
High
135.0
114.5
175
Flange plug with o-ring groove (flange plug including square or round flange respectively, o-ring and bolts)
160
100
Steel
Metric bolts
4 x M30x90
No
High
135.0
114.5
175
Flange plug with o-ring groove (flange plug including square or round flange respectively, o-ring and bolts)
160
125
Steel
Metric bolts
8 x M24x100
No
High
168.0
153.0
200
Flange plug with o-ring groove (flange plug including square or round flange respectively, o-ring and bolts)
160
150
Steel
Metric bolts
8 x M30x110
No
High
210.0
178.0
245
HAVIT - VKB / G-VKB
| Shorttext | Centering flange plug - ND 160 - ISO 6164 |
| Viimeisin muutos | 02.02.2026 13:22:14 |
